Modular cells 2V fitting with standard racks

2V cells with Modular installation for Telecom, Data-Center, Power Plant, etc...
  • Brand:

    GEM BATTERY
  • Item No.:

    GHM 2V Modular cell
  • Payment:

    TT/LC
  • Product origin:

    China
  • Lead Time:

    30 Days
  • Designed Life:

    20 Years
  • Product Details

GEM I GHM Series batteries are Modular batteries.

Rack mounted or container based system configuration 2V mono-block cells, installed horizontally making 24/48/96V power systems. GEM I GHM Series 2V batteries are adopted with AGM Gel technology, the main applications are Telecommunication power, Cellular Data and Towers, Data Center, Solar Power system and Turnkey systems where high-energy power reserve is required. The GEM I GHM Series batteries are are complied with international industrial standards such as IEC 60896 and JISC 8707, as well as the domestic industrial standards, with an extremely long designed life (upto 20 years) in float service, with flexible rack mounted and counting installation.


3-cells module (3 units of 2V cells per layer, making 6V module)

4-cells module (4 units of 2V cells per layer, making 8V module)

6-cells module (6 units of 2V cells per layer, making 12V module)


GHM Series
Voltage
(V)
Capacity
(AH/10HR)
Dimension (in)
Weight
±5%
(lbs)
Dimension (mm)
Weight
±5%
(kgs)
Terminal
±0.04 ±0.04 ±0.08 ±0.08 ±1 ±1 ±2 ±2
L (in) W (in) H (in) TH (in) L (mm) W (mm) H (mm) TH (mm)
GHM 200 2 200 3.74  7.29  14.22  14.66  30.86  95 185 361 372 14.00  M8*20
GHM 300 2 300 4.85  7.29  14.22  14.66  40.79  123 185 361 372 18.50  M8*20
GHM 400 2 400 6.54  7.29  14.22  14.66  54.01  166 185 361 372 24.50  M8*20
GHM 500 2 500 7.68  7.29  14.22  14.66  67.24  195 185 361 372 30.50  M8*20
GHM 600 2 600 8.79  7.29  14.22  14.66  77.16  223 185 361 372 35.00  M8*20
GHM 800 2 800 6.07  9.02  21.87  22.30  114.64  154 229 555 566 52.00  M8*20
GHM 1000 2 1000 7.33  9.02  21.87  22.30  136.69  186 229 555 566 62.00  M8*20
GHM 1200 2 1200 8.87  9.02  21.87  22.30  165.35  225 229 555 566 75.00  M8*20
GHM 1500 2 1500 10.48  9.02  21.87  22.30  202.82  266 229 555 566 92.00  M8*20
GHM 2000 2 2000 13.75  9.18  21.87  22.30  266.76  349 233 555 566 121.00  M8*20
GHM 3000 2 3000 19.54  14.30  14.26  14.74  385.81  496 363 362 374 175.00  M8*20


To download the data sheet of specific model, please Contact us
