GM Series batteries are designed at a larger size and higher capacity than GS Series and carrying more energy power to support more-power-requiring applications. The batteries are using GEM selected models of Pb-Ca-Sn alloyed plates for assembly and adopt AGM technology, complied with IEC60896-21/22.
GEM I GM Series batteries are perfect for commercial power reserve and storage systems. The high-energy-containing could greatly support to high-performance UPS systems, Data Center, Solar Power systems and Telecom Power applications, especially the 12V batteries with High-Rate (HR**) marked models are doing great for critical medical and UPS application, assuring electric power reserve and stable supply. Benefited from the completely sealing structure and high-efficiency of the internal gas recombination.
▷ Main Application:
● Sizable and critical UPS systems ● Solar PV & Wind power
● Medical power assurance ● Telecom & Towers power assurance ● High performance UPS system
● Deep cycle discharge ● Industrial battery & power reserve ● Off-grid power system / Power plant
GEM Battery
GM Series
Voltage
(V)
Capacity
(AH/10HR)
Dimension (mm)
Weight
±3%
(kgs)
±1
±1
±2
±2
L (mm)
W (mm)
H (mm)
TH (mm)
GM 6-170
6
170
260
180
246
252
28.00
GM 6-200
6
200
260
180
270
275
32.00
GM 6-260
6
260
350
180
270
275
45.00
GM 6-300
6
300
295
178
346
350
54.00
GM 6-400
6
400
295
178
404
425
57.50
GEM Battery obtains strong R&D capability to design and develop customized/tailored battery models. If you cannot find a suitable model from our web, please contact us. We will arrange senior sales representatives to follow up your case.
Item: GM 12-55HR (12V55AH/10Hr) size：230*137*210 mm (L*W*H) Weight(kg)：17.50 ( +5% kg/pc) Terminal：M6*16 GEM I GM Series batteries are designed at a larger size and higher capacity than GS Series and carrying more energy power to support more-power-requiring applications. The batteries are using GEM selected models of Pb-Ca-Sn alloyed plates for assembly and adopt AGM technology, complied with IEC60896-21/22. GEM I GM Series batteries are perfect for commercial power reserve and storage systems. The high-energy-containing could greatly support to high-performance UPS systems, Data Center, Solar Power systems and Telecom Power applications, especially the 12V batteries with High-Rate (HR**) marked models are doing great for critical medical and UPS application, assuring electric power reserve and stable supply. Benefited from the completely sealing structure and high-efficiency of the internal gas recombination, the GEM I GM Series batteries are also doing good at Motive Power section, working as the main motive-power source to applications. Application ● UPS system ● Telecom Power assurance ● Solar energy ● Power station & Power plant ● Data-center, BTS & Towers ● Computer network system Technology Adopted with latest and most advanced AGM technology for assembly. Thick and strengthened plates with anti-corruption designed for long life time. Using high purity metal lead/Pb during the production to assure low self-discharge and high power effiency. Flame Retardant UL94 V-0 available on request. Feature assortment General Purpose Standby Power (Float Service) Long Life (Standby) Long Life (Cyclic discharge) High-Rate discharge Deep Cycle (Deep and Cyclic discharge High-Low Temperature (-45ºC to 65ºC) GEM I GM Series Voltage (V) Capacity (AH/10HR) Dimension (in) Weight ±5% (lbs) Dimension (mm) Weight ±5% (kgs) Terminal L (in) W (in) H (in) TH (in) L (mm) W (mm) H (mm) TH (mm) ±0.04 ±0.04 ±0.08 ±0.08 ±1 ±1 ±2 ±2 GM 12-30 12 31 7.64 5.24 6.66 6.70 22.05 194 133 169 170 10.00 M6*12 GM 12-36 HR** 12 36 7.64 5.24 6.66 6.70 25.35 194 133 169 170 11.50 M6*12 GM 12-33 12 33 7.72 5.24 6.34 6.70 23.81 196 133 161 170 10.80 M6*12 GM 12-38 12 38 7.72 6.50 6.62 6.62 28.22 196 165 168 168 12.80 M6*16 GM 12-40 12 40 7.72 6.50 6.62 6.62 29.10 196 165 168 168 13.20 M6*16 GM 12-42 12 42 7.72 6.50 6.62 6.62 30.42 196 165 168 168 13.80 M6*16 GM 12-45 12 45 7.72 6.50 6.62 6.62 31.08 196 165 168 168 14.10 M6*16 GM 12-48 HR** 12 48 7.72 6.50 6.62 6.62 32.19 196 165 168 168 14.60 M6*16 GM 12-50 12 50 9.06 5.40 8.27 8.47 34.17 230 137 210 215 15.50 M6*16 GM 12-55 12 55 9.06 5.40 8.27 8.47 36.38 230 137 210 215 16.50 M6*16 GM 12-55 HR** 12 55 9.06 5.40 8.27 8.47 38.58 230 137 210 215 17.50 M6*16 GM 12-60 12 60 13.79 6.62 7.05 7.05 41.89 350 168 179 179 19.00 M6*16 GM 12-65 12 65 13.79 6.62 7.05 7.05 46.30 350 168 179 179 21.00 M6*16 GM 12-65 HR** 12 65 13.79 6.62 7.05 7.05 51.81 350 168 179 179 23.50 M6*16 GM 12-65C 12 65 13.04 6.86 6.50 6.62 45.19 331 174 165 168 20.50 M6*16 GM 12-60B 12 60 10.24 6.62 8.39 8.51 40.79 260 168 213 216 18.50 M6*16 GM 12-65B 12 65 10.24 6.62 8.39 8.51 44.09 260 168 213 216 20.00 M6*16 GM 12-75 12 75 10.24 6.62 8.39 8.51 47.40 260 168 213 216 21.50 M6*16 GM 12-80 12 80 10.24 6.62 8.39 8.51 49.60 260 168 213 216 22.50 M6*16 GM 12-80 HR** 12 80 10.24 6.62 8.39 8.51 51.81 260 168 213 216 23.50 M6*16 GM 12-90 12 90 12.02 6.58 8.27 8.39 60.63 305 167 210 213 27.50 M6*16 GM 12-100 HR** 12 100 12.02 6.58 8.27 8.39 63.93 305 167 210 213 29.00 M6*16 GM 12-100B 12 100 13.00 6.82 8.55 8.67 63.93 330 173 217 220 29.00 M8*16 GM 12-100A 12 100 13.00 6.82 8.55 8.67 67.90&nbs...
Item: GM 12-100HR (12V100AH/10Hr) Size: 305*167*210 mm (L*W*H) Weight: 29.00 ( +5% kg/pc) Terminal: M6*16 GEM Battery I GM Series batteries are designed at a larger size and higher capacity than GS Series and carrying more energy power to support more-power-requiring applications. The batteries are using GEM selected models of Pb-Ca-Sn alloyed plates for assembly and adopt AGM technology, complied with IEC60896-21/22. The GM Series batteries are rating with 10Hr/C10 capacity. GEM Battery I GM Series batteries are perfect for commercial power reserve and storage systems. The high-energy-containing could greatly support to high-performance UPS systems, Data Center, Solar Power systems and Telecom Power applications, especially the 12V batteries with High-Rate (HR**) marked models are doing great for critical medical and UPS application, assuring electric power reserve and stable supply. Benefited from the completely sealing structure and high-efficiency of the internal gas recombination, the GEM Battery I GM Series batteries are also doing good at Motive Power section, working as the main motive-power source to applications. Application ● UPS system ● Telecom power assurance ● Solar power ● Power station & Power plant ● Data-center, BTS & Towers ● Computer network system Technology Adopted with latest and most advanced AGM technology for assembly. Thick and strengthened plates with anti-corruption designed for long life time. Using high purity metal lead/Pb during the production to assure low self-discharge and high power effiency. Flame Retardant UL94 V-0 available on request. Feature assortment General Purpose Standby Power (Float Service) Long Life (Standby) Long Life (Cyclic discharge) High-Rate discharge Deep Cycle (Deep and Cyclic discharge High-Low Temperature (-45ºC to 65ºC) GEM I GM Series Voltage (V) Capacity (AH/10HR) Dimension (in) Weight ±5% (lbs) Dimension (mm) Weight ±5% (kgs) Terminal L (in) W (in) H (in) TH (in) L (mm) W (mm) H (mm) TH (mm) ±0.04 ±0.04 ±0.08 ±0.08 ±1 ±1 ±2 ±2 GM 12-30 12 31 7.64 5.24 6.66 6.70 22.05 194 133 169 170 10.00 M6*12 GM 12-36 HR** 12 36 7.64 5.24 6.66 6.70 25.35 194 133 169 170 11.50 M6*12 GM 12-33 12 33 7.72 5.24 6.34 6.70 23.81 196 133 161 170 10.80 M6*12 GM 12-38 12 38 7.72 6.50 6.62 6.62 28.22 196 165 168 168 12.80 M6*16 GM 12-40 12 40 7.72 6.50 6.62 6.62 29.10 196 165 168 168 13.20 M6*16 GM 12-42 12 42 7.72 6.50 6.62 6.62 30.42 196 165 168 168 13.80 M6*16 GM 12-45 12 45 7.72 6.50 6.62 6.62 31.08 196 165 168 168 14.10 M6*16 GM 12-48 HR** 12 48 7.72 6.50 6.62 6.62 32.19 196 165 168 168 14.60 M6*16 GM 12-50 12 50 9.06 5.40 8.27 8.47 34.17 230 137 210 215 15.50 M6*16 GM 12-55 12 55 9.06 5.40 8.27 8.47 36.38 230 137 210 215 16.50 M6*16 GM 12-55 HR** 12 55 9.06 5.40 8.27 8.47 38.58 230 137 210 215 17.50 M6*16 GM 12-60 12 60 13.79 6.62 7.05 7.05 41.89 350 168 179 179 19.00 M6*16 GM 12-65 12 65 13.79 6.62 7.05 7.05 46.30 350 168 179 179 21.00 M6*16 GM 12-65 HR** 12 65 13.79 6.62 7.05 7.05 51.81 350 168 179 179 23.50 M6*16 GM 12-65C 12 65 13.04 6.86 6.50 6.62 45.19 331 174 165 168 20.50 M6*16 GM 12-60B 12 60 10.24 6.62 8.39 8.51 40.79 260 168 213 216 18.50 M6*16 GM 12-65B 12 65 10.24 6.62 8.39 8.51 44.09 260 168 213 216 20.00 M6*16 GM 12-75 12 75 10.24 6.62 8.39 8.51 47.40 260 168 213 216 21.50 M6*16 GM 12-80 12 80 10.24 6.62 8.39 8.51 49.60 260 168 213 216 22.50 M6*16 GM 12-80 HR** 12 80 10.24 6.62 8.39 8.51 51.81 260 168 213 216 23.50 M6*16 GM 12-90 12 90 12.02 6.58 8.27 8.39 60.63 305 167 210 213 27.50 M6*16 GM 12-100 HR** 12 100 12.02 6.58 8.27 8.39 63.93 305 167 210 213 29.00 M6*16 GM 12-100B 12 100 13.00 6.82 8.55 8.67 63.93 330 173 217 220 29.00 M8*16 GM 12-100A 12 100 13.00 6...
Item: GM 12-250A (12V250AH/10Hr) Size: 521*269*220 mm (L*W*H) Weight: 72.50 ( +5% kg/pc) Terminal: M8*16 GEM Battery I GM Series batteries are designed at a larger size and higher capacity than GS Series and carrying more energy power to support more-power-requiring applications. The batteries are using GEM selected models of Pb-Ca-Sn alloyed plates for assembly and adopt AGM technology, complied with IEC60896-21/22. The GM Series batteries are rating with 10Hr/C10 capacity. GEM Battery I GM Series batteries are perfect for commercial power reserve and storage systems. The high-energy-containing could greatly support to high-performance UPS systems, Data Center, Solar Power systems and Telecom Power applications, especially the 12V batteries with High-Rate (HR**) marked models are doing great for critical medical and UPS application, assuring electric power reserve and stable supply. Benefited from the completely sealing structure and high-efficiency of the internal gas recombination, the GEM Battery I GM Series batteries are also doing good at Motive Power section, working as the main motive-power source to applications. Application ● UPS system ● Telecom power assurance ● Solar power ● Power station & Power plant ● Data-center, BTS & Towers ● Computer network system Technology Adopted with latest and most advanced AGM technology for assembly. Thick and strengthened plates with anti-corruption designed for long life time. Using high purity metal lead/Pb during the production to assure low self-discharge and high power effiency. Flame Retardant UL94 V-0 available on request. Feature assortment General Purpose Standby Power (Float Service) Long Life (Standby) Long Life (Cyclic discharge) High-Rate discharge Deep Cycle (Deep and Cyclic discharge High-Low Temperature (-45ºC to 65ºC) GEM I GM Series Voltage (V) Capacity (AH/10HR) Dimension (in) Weight ±5% (lbs) Dimension (mm) Weight ±5% (kgs) Terminal L (in) W (in) H (in) TH (in) L (mm) W (mm) H (mm) TH (mm) ±0.04 ±0.04 ±0.08 ±0.08 ±1 ±1 ±2 ±2 GM 12-30 12 31 7.64 5.24 6.66 6.70 22.05 194 133 169 170 10.00 M6*12 GM 12-36 HR** 12 36 7.64 5.24 6.66 6.70 25.35 194 133 169 170 11.50 M6*12 GM 12-33 12 33 7.72 5.24 6.34 6.70 23.81 196 133 161 170 10.80 M6*12 GM 12-38 12 38 7.72 6.50 6.62 6.62 28.22 196 165 168 168 12.80 M6*16 GM 12-40 12 40 7.72 6.50 6.62 6.62 29.10 196 165 168 168 13.20 M6*16 GM 12-42 12 42 7.72 6.50 6.62 6.62 30.42 196 165 168 168 13.80 M6*16 GM 12-45 12 45 7.72 6.50 6.62 6.62 31.08 196 165 168 168 14.10 M6*16 GM 12-48 HR** 12 48 7.72 6.50 6.62 6.62 32.19 196 165 168 168 14.60 M6*16 GM 12-50 12 50 9.06 5.40 8.27 8.47 34.17 230 137 210 215 15.50 M6*16 GM 12-55 12 55 9.06 5.40 8.27 8.47 36.38 230 137 210 215 16.50 M6*16 GM 12-55 HR** 12 55 9.06 5.40 8.27 8.47 38.58 230 137 210 215 17.50 M6*16 GM 12-60 12 60 13.79 6.62 7.05 7.05 41.89 350 168 179 179 19.00 M6*16 GM 12-65 12 65 13.79 6.62 7.05 7.05 46.30 350 168 179 179 21.00 M6*16 GM 12-65 HR** 12 65 13.79 6.62 7.05 7.05 51.81 350 168 179 179 23.50 M6*16 GM 12-65C 12 65 13.04 6.86 6.50 6.62 45.19 331 174 165 168 20.50 M6*16 GM 12-60B 12 60 10.24 6.62 8.39 8.51 40.79 260 168 213 216 18.50 M6*16 GM 12-65B 12 65 10.24 6.62 8.39 8.51 44.09 260 168 213 216 20.00 M6*16 GM 12-75 12 75 10.24 6.62 8.39 8.51 47.40 260 168 213 216 21.50 M6*16 GM 12-80 12 80 10.24 6.62 8.39 8.51 49.60 260 168 213 216 22.50 M6*16 GM 12-80 HR** 12 80 10.24 6.62 8.39 8.51 51.81 260 168 213 216 23.50 M6*16 GM 12-90 12 90 12.02 6.58 8.27 8.39 60.63 305 167 210 213 27.50 M6*16 GM 12-100 HR** 12 100 12.02 6.58 8.27 8.39 63.93 305 167 210 213 29.00 M6*16 GM 12-100B 12 100 13.00 6.82 8.55 8.67 63.93 330 173 217 220 29.00 M8*16 GM 12-100A 12 100 13.00 6....
Item: GM 12-150 (12V150AH/10Hr) Size: 486*171*241 mm (L*W*H) Weight: 45.50 ( +5% kg/pc) Terminal: M8*16 GEM Battery I GM Series batteries are designed at a larger size and higher capacity than GS Series and carrying more energy power to support more-power-requiring applications. The batteries are using GEM selected models of Pb-Ca-Sn alloyed plates for assembly and adopt AGM technology, complied with IEC60896-21/22. The GM Series batteries are rating with 10Hr/C10 capacity. GEM Battery I GM Series batteries are perfect for commercial power reserve and storage systems. The high-energy-containing could greatly support to high-performance UPS systems, Data Center, Solar Power systems and Telecom Power applications, especially the 12V batteries with High-Rate (HR**) marked models are doing great for critical medical and UPS application, assuring electric power reserve and stable supply. Benefited from the completely sealing structure and high-efficiency of the internal gas recombination, the GEM Battery I GM Series batteries are also doing good at Motive Power section, working as the main motive-power source to applications. Application ● UPS system ● Telecom power assurance ● Solar power ● Power station & Power plant ● Data-center, BTS & Towers ● Computer network system Technology Adopted with latest and most advanced AGM technology for assembly. Thick and strengthened plates with anti-corruption designed for long life time. Using high purity metal lead/Pb during the production to assure low self-discharge and high power effiency. Flame Retardant UL94 V-0 available on request. Feature assortment General Purpose Standby Power (Float Service) Long Life (Standby) Long Life (Cyclic discharge) High-Rate discharge Deep Cycle (Deep and Cyclic discharge High-Low Temperature (-45ºC to 65ºC) GEM I GM Series Voltage (V) Capacity (AH/10HR) Dimension (in) Weight ±5% (lbs) Dimension (mm) Weight ±5% (kgs) Terminal L (in) W (in) H (in) TH (in) L (mm) W (mm) H (mm) TH (mm) ±0.04 ±0.04 ±0.08 ±0.08 ±1 ±1 ±2 ±2 GM 12-30 12 31 7.64 5.24 6.66 6.70 22.05 194 133 169 170 10.00 M6*12 GM 12-36 HR** 12 36 7.64 5.24 6.66 6.70 25.35 194 133 169 170 11.50 M6*12 GM 12-33 12 33 7.72 5.24 6.34 6.70 23.81 196 133 161 170 10.80 M6*12 GM 12-38 12 38 7.72 6.50 6.62 6.62 28.22 196 165 168 168 12.80 M6*16 GM 12-40 12 40 7.72 6.50 6.62 6.62 29.10 196 165 168 168 13.20 M6*16 GM 12-42 12 42 7.72 6.50 6.62 6.62 30.42 196 165 168 168 13.80 M6*16 GM 12-45 12 45 7.72 6.50 6.62 6.62 31.08 196 165 168 168 14.10 M6*16 GM 12-48 HR** 12 48 7.72 6.50 6.62 6.62 32.19 196 165 168 168 14.60 M6*16 GM 12-50 12 50 9.06 5.40 8.27 8.47 34.17 230 137 210 215 15.50 M6*16 GM 12-55 12 55 9.06 5.40 8.27 8.47 36.38 230 137 210 215 16.50 M6*16 GM 12-55 HR** 12 55 9.06 5.40 8.27 8.47 38.58 230 137 210 215 17.50 M6*16 GM 12-60 12 60 13.79 6.62 7.05 7.05 41.89 350 168 179 179 19.00 M6*16 GM 12-65 12 65 13.79 6.62 7.05 7.05 46.30 350 168 179 179 21.00 M6*16 GM 12-65 HR** 12 65 13.79 6.62 7.05 7.05 51.81 350 168 179 179 23.50 M6*16 GM 12-65C 12 65 13.04 6.86 6.50 6.62 45.19 331 174 165 168 20.50 M6*16 GM 12-60B 12 60 10.24 6.62 8.39 8.51 40.79 260 168 213 216 18.50 M6*16 GM 12-65B 12 65 10.24 6.62 8.39 8.51 44.09 260 168 213 216 20.00 M6*16 GM 12-75 12 75 10.24 6.62 8.39 8.51 47.40 260 168 213 216 21.50 M6*16 GM 12-80 12 80 10.24 6.62 8.39 8.51 49.60 260 168 213 216 22.50 M6*16 GM 12-80 HR** 12 80 10.24 6.62 8.39 8.51 51.81 260 168 213 216 23.50 M6*16 GM 12-90 12 90 12.02 6.58 8.27 8.39 60.63 305 167 210 213 27.50 M6*16 GM 12-100 HR** 12 100 12.02 6.58 8.27 8.39 63.93 305 167 210 213 29.00 M6*16 GM 12-100B 12 100 13.00 6.82 8.55 8.67 63.93 330 173 217 220 29.00 M8*16 GM 12-100A 12 100 13.00 6.8...
Item: GM 12-200B (12V200AH/10Hr) Size: 523*240*219 mm (L*W*H) Weight: 60.00 ( +5% kg/pc) Terminal: M8*16 GEM Battery I GM Series batteries are designed at a larger size and higher capacity than GS Series and carrying more energy power to support more-power-requiring applications. The batteries are using GEM selected models of Pb-Ca-Sn alloyed plates for assembly and adopt AGM technology, complied with IEC60896-21/22. The GM Series batteries are rating with 10Hr/C10 capacity. GEM Battery I GM Series batteries are perfect for commercial power reserve and storage systems. The high-energy-containing could greatly support to high-performance UPS systems, Data Center, Solar Power systems and Telecom Power applications, especially the 12V batteries with High-Rate (HR**) marked models are doing great for critical medical and UPS application, assuring electric power reserve and stable supply. Benefited from the completely sealing structure and high-efficiency of the internal gas recombination, the GEM Battery I GM Series batteries are also doing good at Motive Power section, working as the main motive-power source to applications. Application ● UPS system ● Telecom power assurance ● Solar power ● Power station & Power plant ● Data-center, BTS & Towers ● Computer network system Technology Adopted with latest and most advanced AGM technology for assembly. Thick and strengthened plates with anti-corruption designed for long life time. Using high purity metal lead/Pb during the production to assure low self-discharge and high power effiency. Flame Retardant UL94 V-0 available on request. Feature assortment General Purpose Standby Power (Float Service) Long Life (Standby) Long Life (Cyclic discharge) High-Rate discharge Deep Cycle (Deep and Cyclic discharge High-Low Temperature (-45ºC to 65ºC) GEM I GM Series Voltage (V) Capacity (AH/10HR) Dimension (in) Weight ±5% (lbs) Dimension (mm) Weight ±5% (kgs) Terminal L (in) W (in) H (in) TH (in) L (mm) W (mm) H (mm) TH (mm) ±0.04 ±0.04 ±0.08 ±0.08 ±1 ±1 ±2 ±2 GM 12-30 12 31 7.64 5.24 6.66 6.70 22.05 194 133 169 170 10.00 M6*12 GM 12-36 HR** 12 36 7.64 5.24 6.66 6.70 25.35 194 133 169 170 11.50 M6*12 GM 12-33 12 33 7.72 5.24 6.34 6.70 23.81 196 133 161 170 10.80 M6*12 GM 12-38 12 38 7.72 6.50 6.62 6.62 28.22 196 165 168 168 12.80 M6*16 GM 12-40 12 40 7.72 6.50 6.62 6.62 29.10 196 165 168 168 13.20 M6*16 GM 12-42 12 42 7.72 6.50 6.62 6.62 30.42 196 165 168 168 13.80 M6*16 GM 12-45 12 45 7.72 6.50 6.62 6.62 31.08 196 165 168 168 14.10 M6*16 GM 12-48 HR** 12 48 7.72 6.50 6.62 6.62 32.19 196 165 168 168 14.60 M6*16 GM 12-50 12 50 9.06 5.40 8.27 8.47 34.17 230 137 210 215 15.50 M6*16 GM 12-55 12 55 9.06 5.40 8.27 8.47 36.38 230 137 210 215 16.50 M6*16 GM 12-55 HR** 12 55 9.06 5.40 8.27 8.47 38.58 230 137 210 215 17.50 M6*16 GM 12-60 12 60 13.79 6.62 7.05 7.05 41.89 350 168 179 179 19.00 M6*16 GM 12-65 12 65 13.79 6.62 7.05 7.05 46.30 350 168 179 179 21.00 M6*16 GM 12-65 HR** 12 65 13.79 6.62 7.05 7.05 51.81 350 168 179 179 23.50 M6*16 GM 12-65C 12 65 13.04 6.86 6.50 6.62 45.19 331 174 165 168 20.50 M6*16 GM 12-60B 12 60 10.24 6.62 8.39 8.51 40.79 260 168 213 216 18.50 M6*16 GM 12-65B 12 65 10.24 6.62 8.39 8.51 44.09 260 168 213 216 20.00 M6*16 GM 12-75 12 75 10.24 6.62 8.39 8.51 47.40 260 168 213 216 21.50 M6*16 GM 12-80 12 80 10.24 6.62 8.39 8.51 49.60 260 168 213 216 22.50 M6*16 GM 12-80 HR** 12 80 10.24 6.62 8.39 8.51 51.81 260 168 213 216 23.50 M6*16 GM 12-90 12 90 12.02 6.58 8.27 8.39 60.63 305 167 210 213 27.50 M6*16 GM 12-100 HR** 12 100 12.02 6.58 8.27 8.39 63.93 305 167 210 213 29.00 M6*16 GM 12-100B 12 100 13.00 6.82 8.55 8.67 63.93 330 173 217 220 29.00 M8*16 GM 12-100A 12 100 13.00 6....
Item: GM 12-230A (12V230AH/10Hr) Size: 521*269*204 mm (L*W*H) Weight: 67.00 ( +5% kg/pc) Terminal: M8*16 GEM Battery I GM Series batteries are designed at a larger size and higher capacity than GS Series and carrying more energy power to support more-power-requiring applications. The batteries are using GEM selected models of Pb-Ca-Sn alloyed plates for assembly and adopt AGM technology, complied with IEC60896-21/22. The GM Series batteries are rating with 10Hr/C10 capacity. GEM Battery I GM Series batteries are perfect for commercial power reserve and storage systems. The high-energy-containing could greatly support to high-performance UPS systems, Data Center, Solar Power systems and Telecom Power applications, especially the 12V batteries with High-Rate (HR**) marked models are doing great for critical medical and UPS application, assuring electric power reserve and stable supply. Benefited from the completely sealing structure and high-efficiency of the internal gas recombination, the GEM Battery I GM Series batteries are also doing good at Motive Power section, working as the main motive-power source to applications. Application ● UPS system ● Telecom power assurance ● Solar power ● Power station & Power plant ● Data-center, BTS & Towers ● Computer network system Technology Adopted with latest and most advanced AGM technology for assembly. Thick and strengthened plates with anti-corruption designed for long life time. Using high purity metal lead/Pb during the production to assure low self-discharge and high power effiency. Flame Retardant UL94 V-0 available on request. Feature assortment General Purpose Standby Power (Float Service) Long Life (Standby) Long Life (Cyclic discharge) High-Rate discharge Deep Cycle (Deep and Cyclic discharge High-Low Temperature (-45ºC to 65ºC) GEM I GM Series Voltage (V) Capacity (AH/10HR) Dimension (in) Weight ±5% (lbs) Dimension (mm) Weight ±5% (kgs) Terminal L (in) W (in) H (in) TH (in) L (mm) W (mm) H (mm) TH (mm) ±0.04 ±0.04 ±0.08 ±0.08 ±1 ±1 ±2 ±2 GM 12-30 12 31 7.64 5.24 6.66 6.70 22.05 194 133 169 170 10.00 M6*12 GM 12-36 HR** 12 36 7.64 5.24 6.66 6.70 25.35 194 133 169 170 11.50 M6*12 GM 12-33 12 33 7.72 5.24 6.34 6.70 23.81 196 133 161 170 10.80 M6*12 GM 12-38 12 38 7.72 6.50 6.62 6.62 28.22 196 165 168 168 12.80 M6*16 GM 12-40 12 40 7.72 6.50 6.62 6.62 29.10 196 165 168 168 13.20 M6*16 GM 12-42 12 42 7.72 6.50 6.62 6.62 30.42 196 165 168 168 13.80 M6*16 GM 12-45 12 45 7.72 6.50 6.62 6.62 31.08 196 165 168 168 14.10 M6*16 GM 12-48 HR** 12 48 7.72 6.50 6.62 6.62 32.19 196 165 168 168 14.60 M6*16 GM 12-50 12 50 9.06 5.40 8.27 8.47 34.17 230 137 210 215 15.50 M6*16 GM 12-55 12 55 9.06 5.40 8.27 8.47 36.38 230 137 210 215 16.50 M6*16 GM 12-55 HR** 12 55 9.06 5.40 8.27 8.47 38.58 230 137 210 215 17.50 M6*16 GM 12-60 12 60 13.79 6.62 7.05 7.05 41.89 350 168 179 179 19.00 M6*16 GM 12-65 12 65 13.79 6.62 7.05 7.05 46.30 350 168 179 179 21.00 M6*16 GM 12-65 HR** 12 65 13.79 6.62 7.05 7.05 51.81 350 168 179 179 23.50 M6*16 GM 12-65C 12 65 13.04 6.86 6.50 6.62 45.19 331 174 165 168 20.50 M6*16 GM 12-60B 12 60 10.24 6.62 8.39 8.51 40.79 260 168 213 216 18.50 M6*16 GM 12-65B 12 65 10.24 6.62 8.39 8.51 44.09 260 168 213 216 20.00 M6*16 GM 12-75 12 75 10.24 6.62 8.39 8.51 47.40 260 168 213 216 21.50 M6*16 GM 12-80 12 80 10.24 6.62 8.39 8.51 49.60 260 168 213 216 22.50 M6*16 GM 12-80 HR** 12 80 10.24 6.62 8.39 8.51 51.81 260 168 213 216 23.50 M6*16 GM 12-90 12 90 12.02 6.58 8.27 8.39 60.63 305 167 210 213 27.50 M6*16 GM 12-100 HR** 12 100 12.02 6.58 8.27 8.39 63.93 305 167 210 213 29.00 M6*16 GM 12-100B 12 100 13.00 6.82 8.55 8.67 63.93 330 173 217 220 29.00 M8*16 GM 12-100A 12 100 13.00 6....
Item: GM 12-135 (12V135AH/10Hr) Size: 341*172*283 mm (L*W*H) Weight: 42.00 ( +5% kg/pc) Terminal: M8*16 GEM Battery I GM Series batteries are designed at a larger size and higher capacity than GS Series and carrying more energy power to support more-power-requiring applications. The batteries are using GEM selected models of Pb-Ca-Sn alloyed plates for assembly and adopt AGM technology, complied with IEC60896-21/22. The GM Series batteries are rating with 10Hr/C10 capacity. GEM Battery I GM Series batteries are perfect for commercial power reserve and storage systems. The high-energy-containing could greatly support to high-performance UPS systems, Data Center, Solar Power systems and Telecom Power applications, especially the 12V batteries with High-Rate (HR**) marked models are doing great for critical medical and UPS application, assuring electric power reserve and stable supply. Benefited from the completely sealing structure and high-efficiency of the internal gas recombination, the GEM Battery I GM Series batteries are also doing good at Motive Power section, working as the main motive-power source to applications. Application ● UPS system ● Telecom power assurance ● Solar power ● Power station & Power plant ● Data-center, BTS & Towers ● Computer network system Technology Adopted with latest and most advanced AGM technology for assembly. Thick and strengthened plates with anti-corruption designed for long life time. Using high purity metal lead/Pb during the production to assure low self-discharge and high power effiency. Flame Retardant UL94 V-0 available on request. Feature assortment General Purpose Standby Power (Float Service) Long Life (Standby) Long Life (Cyclic discharge) High-Rate discharge Deep Cycle (Deep and Cyclic discharge High-Low Temperature (-45ºC to 65ºC) GEM I GM Series Voltage (V) Capacity (AH/10HR) Dimension (in) Weight ±5% (lbs) Dimension (mm) Weight ±5% (kgs) Terminal L (in) W (in) H (in) TH (in) L (mm) W (mm) H (mm) TH (mm) ±0.04 ±0.04 ±0.08 ±0.08 ±1 ±1 ±2 ±2 GM 12-30 12 31 7.64 5.24 6.66 6.70 22.05 194 133 169 170 10.00 M6*12 GM 12-36 HR** 12 36 7.64 5.24 6.66 6.70 25.35 194 133 169 170 11.50 M6*12 GM 12-33 12 33 7.72 5.24 6.34 6.70 23.81 196 133 161 170 10.80 M6*12 GM 12-38 12 38 7.72 6.50 6.62 6.62 28.22 196 165 168 168 12.80 M6*16 GM 12-40 12 40 7.72 6.50 6.62 6.62 29.10 196 165 168 168 13.20 M6*16 GM 12-42 12 42 7.72 6.50 6.62 6.62 30.42 196 165 168 168 13.80 M6*16 GM 12-45 12 45 7.72 6.50 6.62 6.62 31.08 196 165 168 168 14.10 M6*16 GM 12-48 HR** 12 48 7.72 6.50 6.62 6.62 32.19 196 165 168 168 14.60 M6*16 GM 12-50 12 50 9.06 5.40 8.27 8.47 34.17 230 137 210 215 15.50 M6*16 GM 12-55 12 55 9.06 5.40 8.27 8.47 36.38 230 137 210 215 16.50 M6*16 GM 12-55 HR** 12 55 9.06 5.40 8.27 8.47 38.58 230 137 210 215 17.50 M6*16 GM 12-60 12 60 13.79 6.62 7.05 7.05 41.89 350 168 179 179 19.00 M6*16 GM 12-65 12 65 13.79 6.62 7.05 7.05 46.30 350 168 179 179 21.00 M6*16 GM 12-65 HR** 12 65 13.79 6.62 7.05 7.05 51.81 350 168 179 179 23.50 M6*16 GM 12-65C 12 65 13.04 6.86 6.50 6.62 45.19 331 174 165 168 20.50 M6*16 GM 12-60B 12 60 10.24 6.62 8.39 8.51 40.79 260 168 213 216 18.50 M6*16 GM 12-65B 12 65 10.24 6.62 8.39 8.51 44.09 260 168 213 216 20.00 M6*16 GM 12-75 12 75 10.24 6.62 8.39 8.51 47.40 260 168 213 216 21.50 M6*16 GM 12-80 12 80 10.24 6.62 8.39 8.51 49.60 260 168 213 216 22.50 M6*16 GM 12-80 HR** 12 80 10.24 6.62 8.39 8.51 51.81 260 168 213 216 23.50 M6*16 GM 12-90 12 90 12.02 6.58 8.27 8.39 60.63 305 167 210 213 27.50 M6*16 GM 12-100 HR** 12 100 12.02 6.58 8.27 8.39 63.93 305 167 210 213 29.00 M6*16 GM 12-100B 12 100 13.00 6.82 8.55 8.67 63.93 330 173 217 220 29.00 M8*16 GM 12-100A 12 100 13.00 6.8...
Item: GM 12-200A (12V200AH/10Hr) Size: 523*240*219 mm (L*W*H) Weight: 65.00 ( +5% kg/pc) Terminal: M8*16 GEM Battery I GM Series batteries are designed at a larger size and higher capacity than GS Series and carrying more energy power to support more-power-requiring applications. The batteries are using GEM selected models of Pb-Ca-Sn alloyed plates for assembly and adopt AGM technology, complied with IEC60896-21/22. The GM Series batteries are rating with 10Hr/C10 capacity. GEM Battery I GM Series batteries are perfect for commercial power reserve and storage systems. The high-energy-containing could greatly support to high-performance UPS systems, Data Center, Solar Power systems and Telecom Power applications, especially the 12V batteries with High-Rate (HR**) marked models are doing great for critical medical and UPS application, assuring electric power reserve and stable supply. Benefited from the completely sealing structure and high-efficiency of the internal gas recombination, the GEM Battery I GM Series batteries are also doing good at Motive Power section, working as the main motive-power source to applications. Application ● UPS system ● Telecom power assurance ● Solar power ● Power station & Power plant ● Data-center, BTS & Towers ● Computer network system Technology Adopted with latest and most advanced AGM technology for assembly. Thick and strengthened plates with anti-corruption designed for long life time. Using high purity metal lead/Pb during the production to assure low self-discharge and high power effiency. Flame Retardant UL94 V-0 available on request. Feature assortment General Purpose Standby Power (Float Service) Long Life (Standby) Long Life (Cyclic discharge) High-Rate discharge Deep Cycle (Deep and Cyclic discharge High-Low Temperature (-45ºC to 65ºC) GEM I GM Series Voltage (V) Capacity (AH/10HR) Dimension (in) Weight ±5% (lbs) Dimension (mm) Weight ±5% (kgs) Terminal L (in) W (in) H (in) TH (in) L (mm) W (mm) H (mm) TH (mm) ±0.04 ±0.04 ±0.08 ±0.08 ±1 ±1 ±2 ±2 GM 12-30 12 31 7.64 5.24 6.66 6.70 22.05 194 133 169 170 10.00 M6*12 GM 12-36 HR** 12 36 7.64 5.24 6.66 6.70 25.35 194 133 169 170 11.50 M6*12 GM 12-33 12 33 7.72 5.24 6.34 6.70 23.81 196 133 161 170 10.80 M6*12 GM 12-38 12 38 7.72 6.50 6.62 6.62 28.22 196 165 168 168 12.80 M6*16 GM 12-40 12 40 7.72 6.50 6.62 6.62 29.10 196 165 168 168 13.20 M6*16 GM 12-42 12 42 7.72 6.50 6.62 6.62 30.42 196 165 168 168 13.80 M6*16 GM 12-45 12 45 7.72 6.50 6.62 6.62 31.08 196 165 168 168 14.10 M6*16 GM 12-48 HR** 12 48 7.72 6.50 6.62 6.62 32.19 196 165 168 168 14.60 M6*16 GM 12-50 12 50 9.06 5.40 8.27 8.47 34.17 230 137 210 215 15.50 M6*16 GM 12-55 12 55 9.06 5.40 8.27 8.47 36.38 230 137 210 215 16.50 M6*16 GM 12-55 HR** 12 55 9.06 5.40 8.27 8.47 38.58 230 137 210 215 17.50 M6*16 GM 12-60 12 60 13.79 6.62 7.05 7.05 41.89 350 168 179 179 19.00 M6*16 GM 12-65 12 65 13.79 6.62 7.05 7.05 46.30 350 168 179 179 21.00 M6*16 GM 12-65 HR** 12 65 13.79 6.62 7.05 7.05 51.81 350 168 179 179 23.50 M6*16 GM 12-65C 12 65 13.04 6.86 6.50 6.62 45.19 331 174 165 168 20.50 M6*16 GM 12-60B 12 60 10.24 6.62 8.39 8.51 40.79 260 168 213 216 18.50 M6*16 GM 12-65B 12 65 10.24 6.62 8.39 8.51 44.09 260 168 213 216 20.00 M6*16 GM 12-75 12 75 10.24 6.62 8.39 8.51 47.40 260 168 213 216 21.50 M6*16 GM 12-80 12 80 10.24 6.62 8.39 8.51 49.60 260 168 213 216 22.50 M6*16 GM 12-80 HR** 12 80 10.24 6.62 8.39 8.51 51.81 260 168 213 216 23.50 M6*16 GM 12-90 12 90 12.02 6.58 8.27 8.39 60.63 305 167 210 213 27.50 M6*16 GM 12-100 HR** 12 100 12.02 6.58 8.27 8.39 63.93 305 167 210 213 29.00 M6*16 GM 12-100B 12 100 13.00 6.82 8.55 8.67 63.93 330 173 217 220 29.00 M8*16 GM 12-100A 12 100 13.00 6....
Our team of expert staffs are ready to cooperate with you and to provide professional service. You would get replied immediately with valuable information. Let our cooperation get started soon!
